Pinched Nasal Tip Repair

Pinched Nose Following Rhinoplasty

RevRhino140FrontalBeforeThis is a great case example that demonstrates repair of a pinched nasal tip. This gentleman had previously undergone rhinoplasty surgery performed by a different plastic surgeon a few decades ago. Unfortunately, as time went on, his nasal tip began to collapse on both sides – resulting in pinching of the nostril side walls. This is readily seen in his preoperative frontal photograph shown here. Not only did this type of problem result in an abnormal cosmetic appearance – the pinched nasal tip also created problems in terms of breathing. After researching revision rhinoplasty surgeons online, he decided to drive down to San Diego to consult with me in person. Although there was a good number of board certified plastic surgeons in his local area, he felt that my experience and qualifications in revision rhinoplasty were better suited for his particular case.

Pinched Nose Evaluation

During his consultation I was able to confirm for him the precise reason why his nasal tip collapsed following his original rhinoplasty surgery. The way I explained this to him is shown visually below.
RevRhino140FrontalBeforeSeriesIn the normal, structurally sound nose, the nasal tip gets it’s shape from the underlying cartilage framework. These two segments of cartilage are referred to as the lower lateral cartilages, or LLCs. The pair is typically fairly symmetrical in size and shape. As you can see, the lower lateral cartilages normally extend out away from the midline – sort of mimicking a pair wings when seen from the front. These wings are what helps to provide support to the side walls of the nostrils.In this particular case, the patient’s past rhinoplasty surgeon ended up resecting, or removing, a good portion of the lower lateral cartilages. This is shown graphically in the above photo where you can see a good portion of the lower lateral cartilage has been erased away. This was likely done in an attempt to create a more defined nasal tip. Unfortunately, this particular technique, called cephalic trimming, can be dangerous if too much of the lower lateral cartilage is removed without providing reinforcement in some other manner. In the beginning of the healing process, the problem is not real evident. But as time goes on (6-12 months after surgery), the nose begins to pinch in on both sides of the tip because there is now a relative lack of cartilage support. This evolution is represented by the red arrows in the above photo – showing how the nasal tip slowly pinches inward on both sides.

The end result is a nasal tip that has harsh shadowing on both sides – often times a telltale sign of prior rhinoplasty surgery. In addition, the nostril support is compromised – leading to trouble breathing through the nose because of the structural collapse.

Rhinoplasty Repair for Pinched Nose

RevRhino140FrontalGraftsBased on the underlying problem, I recommended this patient undergo an open revision rhinoplasty procedure to help repair his pinched nasal tip. An open approach was necessary in order to have an optimal view of the collapsed cartilage and to allow precise placement of the grafts needed to restore proper support.

In concept, I planned on using cartilage grafts to help rebuild his pinched nasal tip. In the end, we chose to use cadaveric costal cartilage – also known as rib cartilage taken from a tissue bank. I would have used septal cartilage from inside of his nose, however, there was none left following his prior surgery. What about using ear cartilage? This was an option in his case, but I felt the rib cartilage graft would provide a more stable repair and more sturdy long-term result.

The above photo shows essentially how the rib cartilage grafting was performed to help repair the pinched nasal tip. I ended up creating cartilage grafts that extended from the midline out toward the side of the nostrils. Out toward the side, the cartilage grafts were very carefully positioned inside of what we call a ‘precise pocket’ so that they would stay put during the healing process. More toward the center of the nose, the cartilage grafts were secured to the remaining segments of the lower lateral cartilage. What this allowed me to do was reverse the pinching effect that was seen preoperatively (see green arrows). His surgery went quite well without any complication. At the same time, this patient also required a spreader, splinting graft that was placed on his right side to help provide further reinforcement to his cartilage framework.

Pinched Nose Repair Results

Here are his results following my revision rhinoplasty. As you can see from this front view, his nasal tip is no longer pinched with abnormal shadowing along each side. The tip of his nose now has more of a convex overall shape, which is normal.
RevRhino140FrontalBA On this base view of his nose, you can really see how the nostril support has been improved with revision rhinoplasty. He now has more of what we call a ‘soft triangle’ outlined appearance to his nose – instead of the pinched, collapsed nostril walls that can be seen before surgery.
RevRhino140BaseBA On this oblique view, you can also appreciate the improvements made to the nose. More specifically, you can see how the pinched nostrils are now more rounded – precisely the goal of the revision rhinoplasty.
RevRhino140OblBA His other oblique view, you can see how symmetry was relatively preserved with the cartilage grafting technique.

Revision Rhinoplasty Consult

If you feel that revision rhinoplasty surgery may benefit your nose, do not hesitate in contacting my office today. In the meantime, take a closer look at our online rhinoplasty tutorial, which helps provide patients like you a more in-depth understanding of this very complex, yet satisfying, plastic surgery procedure.
